The UL1571 PVC Cable represents a foundational component for modern electrical engineering, specifically formulated to bridge the gap between compact flexibility and uncompromising safety. When you handle this wire, the first thing you notice is the smooth, non-tacky finish of the SR-PVC (Semi-Rigid Polyvinyl Chloride) jacket. This distinct texture is intentionally engineered to reduce friction, allowing the cable to glide effortlessly through narrow conduits and tight appliance chassis without snagging. Beneath this resilient exterior lies a core of high-purity copper—available in both tinned and bare configurations. The tinned variant offers a bright, silver-like sheen that actively repels oxidation, ensuring long-term solderability and maintaining a pristine connection even in environments prone to humidity. Designed primarily for the internal wiring of sensitive electronic equipment, precision instruments, and consumer appliances, this extension cord wire provides a dependable pathway for critical control circuits. Furthermore, strict adherence to global RoHS and REACH environmental directives means this product is free from restricted hazardous substances, facilitating smooth, compliant entry into international markets for your finished goods.

Core Electrical & Mechanical Specifications

The physical and electrical integrity of internal wiring dictates the operational lifespan and safety of the entire electrical system. The UL1571 specification is meticulously structured to deliver consistent, predictable performance under continuous thermal and electrical stress. Below are the foundational parameters that define this cable's capabilities:

• Rated Voltage: 30V

• Rated Temperature: 80ºC

• Insulation Material: SR-PVC

• Conductor: Tinned or Bare, Stranded or Solid Copper

• Reference Standard: UL758, UL1581, C22.2 No.210

• Passes UL VW-1 & CSA FT1 vertical flame test.

• Uniform insulation thickness of wire to ensure easy stripping and cutting.

• For internal wiring of electronic and electrical equipment and appliance, wiring circuits, control circuits, etc.

Beyond these baseline metrics, the true value of this wire lies in its processing efficiency. The manufacturing process ensures an extremely low eccentricity rate, meaning the copper core remains perfectly centered within the PVC jacket. This uniform insulation thickness is palpable when handling the wire; it strips cleanly and instantly without catching or tearing. For facilities utilizing high-speed automated harness processing machines, this translates directly to fewer machine jams, zero accidental nicking of the copper strands, and significantly enhanced throughput. On the safety front, passing the rigorous UL VW-1 and CSA FT1 vertical flame tests provides a critical layer of fire resistance. In the event of a thermal overload, the SR-PVC material is designed to self-extinguish rapidly, preventing the spread of fire and protecting the broader circuit architecture.

Technical Data Sheet: Conductor and Insulation Dimensions

Precision is paramount when routing cables through densely packed appliance housings or intricate control panels. The following technical data sheet outlines the exact dimensional tolerances, stranding configurations, and maximum conductor resistance for the complete UL1571 series. Engineers and sourcing teams rely on this exact metric data to accurately calculate conduit fill capacities, thermal dissipation, and overall space requirements.

From the ultra-fine 32 AWG, which is exceptionally pliable and suited for micro-electronics, to the heavy-duty 18 AWG designed for higher current loads, each gauge maintains a strict outer diameter profile. This consistency ensures flawless compatibility with standard terminal blocks, crimp connectors, and automated stripping blades. Notice the steady, proportional scaling of the maximum conductor resistance at 20°C. This provides a highly reliable baseline for calculating voltage drop across longer extension runs, ensuring that your final product performs exactly as engineered, batch after batch.

Advanced Quality Control & Customization Capabilities

Securing a reliable component supply chain requires more than just meeting standard specifications; it demands rigorous validation, adaptable manufacturing, and a commitment to long-term consistency. Every spool of our copper extension wire undergoes a battery of physical and electrical assessments before being approved for shipment.

Stringent Factory Testing Protocols: Quality is verified through intensive, multi-stage testing. We subject the continuous length of insulation to high-voltage spark testing to detect even microscopic pinholes, ensuring absolute dielectric integrity across the entire spool. Conductor resistance is meticulously measured to guarantee optimal power delivery without excessive heat generation. Additionally, physical tensile strength tests confirm that the wire can withstand the mechanical pulling, bending, and routing inherent in complex assembly lines without compromising its internal structure.

Flexible Production and Customization: Recognizing that different manufacturing setups have unique operational requirements, this cable series is highly adaptable. We offer the full spectrum of wire gauges—ranging from the heavy-duty 18 AWG down to the delicate 32 AWG—in a wide array of vibrant jacket colors. This variety facilitates intuitive, error-free color-coding in complex multi-wire harnesses. Packaging can also be tailored to your specific feeding equipment, available in both compact, easy-to-handle coils and large-capacity wooden or plastic spools to minimize changeover downtime on your factory floor.

Consistent Capacity and Rapid Delivery: Supported by optimized extrusion lines and a highly stable raw material supply network, we maintain the substantial capacity required to fulfill large-scale production demands promptly. This operational stability ensures your manufacturing schedules remain completely uninterrupted, backed by a component that delivers the exact same tactile feel, flexibility, and electrical performance in every single delivery.
